Structural Drying in Vacaville, CA

A surface can feel dry while the bottom plate of a wall, the subfloor or the slab under it is still wet. Structural drying is the process of getting the building materials themselves back to their normal moisture level, measured with meters, before anything is closed up or rebuilt.

How the dry-out is set up

• Moisture mapping with thermal imaging and pinless and pin meters before any equipment goes down
• Air movers placed to each room's evaporation load, aimed along wet walls and floors
• LGR dehumidifiers that pull the evaporated water back out of the air
• Desiccant units and mat systems for dense Class 4 materials like concrete, hardwood and plaster
• Small holes or removed baseboards to push dry air into wall cavities

Class 1 through 4

The IICRC S500 standard sorts a loss by how much water was absorbed. Class 1 is a small area with little absorbed water. Class 2 means carpet and walls wet up to about two feet. Class 3 is water that came from above and soaked walls, ceilings and insulation. Class 4 covers dense materials that hold water tightly. The class sets how many air movers and how much dehumidification a room needs.

Readings decide when it is done

The drying team records the temperature and humidity inside and outside the drying area and the moisture in the materials every day. The goal is for wet materials to read within 2 to 4 points of a dry reference material in an unaffected part of the same building. Equipment comes out when the log says so, not on a set date. That log becomes part of the insurance file.

Vacaville's dry summer air speeds drying; cool, damp winter storms slow it. The drying-time estimator gives a rough range. The EPA home moisture page explains why drying within 24 to 48 hours matters, and hardwood has its own method on the hardwood floor drying page.
